| Model |
IT-737 |
IT-757 |
| Q'ty of Electrolytic Plate |
3 pieces plate |
5/7/9 pieces plates |
| Voltage |
AC110V / AC220V 50/60HZ |
AC110V / AC220V 50/60HZ |
| Power Consumption |
Max 180W |
Max 230W |
| Inlet Water Pressure |
09-5.0 kg/cm² |
09-5.0 kg/cm² |
| Electrolysis Method |
Continuous electrolysis (built-in flow meter) |
Continuous electrolysis (built-in flow meter) |
| Water Flow Rate |
Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kgf/cm²)
Water flow rate: 3 Liters/min (based on inlet water pressure 2kgf/cm²) |
Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kgf/cm²)
Water flow rate: 3 Liters/min (based on inlet water pressure 2kgf/cm²) |
| Display |
PH, O.R.P, water flow rate, working status, clean, pure, alkaline, acidity and filter service life |
PH, O.R.P, water flow rate, working status, clean, pure, alkaline, acidity and filter service life |
| Cleaning |
Automatic cleaning for 10 seconds after each use of alkaline water
manual deaning only if Alkaline water consumption is up to 30 liters |
Automatic cleaning for 10 seconds after each use of alkaline water
manual deaning only if Alkaline water consumption is up to 30 liters |
| Electrolysis levels |
4 Alkaline levels, 1 Neutral level and 2 Acidic levels |
4 Alkaline levels, 1 Neutral level and 2 Acidic levels |
| pH Adjustment |
Each electrolysis level gives 20 segments for pH adjustment (based on water source quality in different areas) |
Each electrolysis level gives 20 segments for pH adjustment (based on water source quality in different areas) |
| Filter Material |
Activated carbon fiber (ACF), made in USA and approved by NSF certificate |
Activated carbon fiber (ACF), made in USA and approved by NSF certificate |
| Filter Service Life |
About 12,000 liters (depend on water resource quality) |
About 12,000 liters (depend on water resource quality) |
| Safety Protection Device |
Current protection & Alarm only if drinking Acid water |
Current protection & Alarm only if drinking Acid water |
| Dimension & Weight |
H 310mm x W 220mm x D 125mm (Approx)
Weight: 40 kos (Approx) |
H 310mm x W 220mm x D 125mm (Approx)
Weight: 40 kos (Approx) |
| PH Value (based on source water quality) |
5-10 |
4.5-11 |
| QRP Value (Dased on source water qualityl) |
-650mv (Max) |
5 Plates: -800mv (Max.)
7 Plates: -850mv(Max.)
9 Plates: -900mv(Max.) |
